Exact configuration / US market
2024 / 2020–2024 / AWD
Tesla Model YPerformance AWD
The 21-inch staggered Performance configuration with its distinct rear brakes, clearance, tires, and EPA record.
No vehicle image published
The pilot ships original abstract art only; vehicle photography waits for reusable rights.
01 / Key facts
All recorded specifications
Values are grouped by system; use the source link on any row to inspect its evidence.
Identity
7| Fact | Value | Evidence | Source |
|---|---|---|---|
| Model year | 2024 | Verified | Model Y Owner’s Manual, 2020–2024Model year / cover |
| Market | United States | Verified | Model Y Owner’s Manual, 2020–2024US-market publication |
| Body style | Five-door compact crossover | Verified | Model Y Owner’s Manual, 2020–2024Vehicle description |
| Doors | 5 | Verified | Model Y Owner’s Manual, 2020–2024Vehicle description |
| Seats | 5 | Verified | Model Y Owner’s Manual, 2020–2024Interior dimensions / five-seat configuration |
| FuelEconomy.gov record | 47914 | Verified | FuelEconomy.gov vehicle recordsVehicle record 47914 |
| EPA vehicle class | Small Sport Utility Vehicle 2WD/4WD | Verified | FuelEconomy.gov vehicle recordsVehicle record 47914 / VClass |
Powertrain
6| Fact | Value | Evidence | Source |
|---|---|---|---|
| Powertrain | Dual-motor battery electric | Verified | Model Y Owner’s Manual, 2020–2024Electric vehicle components |
| Front motor type | AC induction, liquid-cooled | Verified | Model Y Owner’s Manual, 2020–2024Motors |
| Rear motor type | AC permanent-magnet synchronous, liquid-cooled | Verified | Model Y Owner’s Manual, 2020–2024Motors |
| EPA motor descriptionThe EPA label is retained as source text; Tesla’s owner manual identifies the rear unit as permanent-magnet and the AWD front unit as induction. | 135 + 243 kW AC induction (EPA record wording) | Verified | FuelEconomy.gov vehicle recordsVehicle record 47914 / evMotor |
| Gross battery capacity | Not published for this exact 2024 configuration | Unverified | Model Y Owner’s Manual, 2020–2024Owner-manual publication gap |
| Usable battery capacity | Not published for this exact 2024 configuration | Unverified | Model Y Owner’s Manual, 2020–2024Owner-manual publication gap |
Transmission
2| Fact | Value | Evidence | Source |
|---|---|---|---|
| Transmission | Single-speed fixed gear | Verified | Model Y Owner’s Manual, 2020–2024Transmission |
| Driven wheels | All-wheel drive | Verified | Model Y Owner’s Manual, 2020–2024Drive unit layout |
Gearing
1| Fact | Value | Evidence | Source |
|---|---|---|---|
| Fixed reduction | 9:1 | Verified | Model Y Owner’s Manual, 2020–2024Gearbox ratio |
Chassis and steering
5| Fact | Value | Evidence | Source |
|---|---|---|---|
| Front suspension | Independent double wishbone / virtual steering axis | Verified | Model Y Owner’s Manual, 2020–2024Suspension |
| Rear suspension | Independent multi-link | Verified | Model Y Owner’s Manual, 2020–2024Suspension |
| Steering | Electric power rack-and-pinion | Verified | Model Y Owner’s Manual, 2020–2024Steering |
| Turns lock-to-lock | 2 | Verified | Model Y Owner’s Manual, 2020–2024Steering specifications |
| Turning circle | 39.8 ft | Verified | Model Y Owner’s Manual, 2020–2024Steering specifications |
Brakes
4| Fact | Value | Evidence | Source |
|---|---|---|---|
| Brake systems | ABS, electronic brake-force distribution, and regenerative braking | Verified | Model Y Owner’s Manual, 2020–2024Braking systems |
| Front rotor | 355 × 25 mm ventilated; 23 mm service limit | Verified | Model Y Owner’s Manual, 2020–2024Brake specifications |
| Rear rotor | 335 × 22 mm; 20 mm service limit | Verified | Model Y Owner’s Manual, 2020–2024Brake specifications |
| Rotor lateral runout limit | 0 in | Verified | Model Y Owner’s Manual, 2020–2024Brake specifications |
Dimensions and capacity
16Wheels and tires
3| Fact | Value | Evidence | Source |
|---|---|---|---|
| 21-in wheels F/R | 21 × 9.5J ET40 / 21 × 10.5J ET48 | Verified | Model Y Owner’s Manual, 2020–2024Wheels and tires |
| 21-in tires F/R | 255/35R21 XL / 275/35R21 XL | Verified | Model Y Owner’s Manual, 2020–2024Wheels and tires |
| Wheel lug torque | 129 lb-ft | Verified | Model Y Owner’s Manual, 2020–2024Wheel nut torque |
Efficiency
2| Fact | Value | Evidence | Source |
|---|---|---|---|
| EPA combined MPGe | 105 MPGe | Verified | FuelEconomy.gov vehicle recordsVehicle record 47914 / comb08 |
| EPA combined energy use | 32.2 kWh/100 mi | Verified | FuelEconomy.gov vehicle recordsVehicle record 47914 / combE |
Range
1| Fact | Value | Evidence | Source |
|---|---|---|---|
| EPA electric range | 279 mi | Verified | FuelEconomy.gov vehicle recordsVehicle record 47914 / range |
Charging
1| Fact | Value | Evidence | Source |
|---|---|---|---|
| 240 V charge time | 9.8 hours | Verified | FuelEconomy.gov vehicle recordsVehicle record 47914 / charge240 |
Emissions
1| Fact | Value | Evidence | Source |
|---|---|---|---|
| EPA tailpipe emissions | 0 g/mi tailpipe CO₂ | Verified | FuelEconomy.gov vehicle recordsVehicle record 47914 / co2TailpipeGpm |
Source register
Published facts are exact; unpublished trim curb weight and battery capacity are shown as unverified gaps.
Model Y Owner’s Manual, 2020–2024
Historical manual, intentionally used instead of the current-model specification page.
- Applies to
- United States, Model Y 2020–2024
- Retrieved
- 2026-08-26
FuelEconomy.gov vehicle records
Official US efficiency, range, energy-use, class, and emissions records.
- Applies to
- United States, 2024 model year
- Retrieved
- 2026-08-26
